Solomix 2 VLH TMR mixer

    The Solomix 2 VLH is a feed mixer with two vertical mixing augers and a front-discharging cross conveyor belt (B) or (curved (C)) cross conveyor chain (K). The mixer wagon is also available with a cross conveyor chain at the front for a trough. The discharge happens with a cross conveyor chain in combination with a retractable extension chain (S). All types are available in volumes of 430-1285 cu.ft. Our patented ’Dual Flow’ system ensures the feed is perfectly mixed. Click here for an overview of the unique characteristics of our feed mixers or read more about the use of magnet in your mixer wagon.

    attributes

    Capacity 430-1285 cu.ft.
    Discharge type Front discharge
    Model Trailed
    Strawblower No

    Choice of discharging units

      Explanation of abbreviations

      • VL = Front discharge
      • H = High discharge unit
      • L = Low discharge unit
      • B = Synthetic conveyor belt
      • K = Conveyor chain
      • C = Curved conveyor chain
      • S = Vold down chain conveyor
      • ZK = Side discharge doors
      • X = Heavy Duty

      Photos

      Video

      Standard features

      • Unique two auger drive system
      • 2 Long Life Twin Stream augers (7/8"flighting / 1"wings) for quick mixing and superior discharge
      • Hand jack
      • Adjustable and reversible open and low drawbar with clevis
      • Wear ring
      • Two windows in discharge unit
      • Constant velocity PTO shaft
      • Two manual operated restrictor blades (reversible)
      • Hydraulic brake system
      • Two wide or large wheels
      • Two Heavy Duty planetary drives
      • Remote control by bowden cable operation
      • Trioform auger knives short
      • Dual Flow: Improved shape of the mixing tub and offset inserts
      • New stairs with platform and windows, in height adjustable arm for weighing indicator and guidance of hydraulic hoses with storage possibility
      • Larger discharge door with rounded edges for better discharge
      • Walking tandem axle with four wide wheels (VLH-T)

      Technical specifications

      Solomix 2 VLH 1200 1400 1500 1600  1600L 1800 2000 2000L 2400
      Capacity cu.ft. 430 500 540 570 570 650 715 715 860
      Overall length 259" 265" 278" 279" 296" 298 300" 315" 302"
      Width outside tires 67" 71" 75" 75" 84" 84" 84" 84" 84"
      Overall height 99" 108" 104" 109" 106" 111" 119" 106" 127"
      PTO Drive 540 540 540 540 540 540 540 540 540
      Tractor power requirement HP (kW) 82 (60) 82 (60) 85 (62) 85 (62) 102 (75) 102 (75) 102 (75) 112 (82) 109 (80)
      Tire size  400/45
      L 17.5
      (2 x)
      400/45
      L 17.5
      (2 x)
      235/75
      R 17.5
      (4 x)
      235/75
      R 17.5
      (2 x)
      435/50
      R 19.5
      (2 x)
      435/50
      R 19.5
      (2 x)
      435/50
      R 19.5
      (2 x)
      435/50
      R 19.5
      (2 x)
      435/50
      R 19.5
      (2 x)

      .

      Solomix 2 VLH-T 1600L  1800 2000 2000L 2400
      Capacity cu.ft. 570 650 715 715 860
      Overall length  296" 298" 300" 315" 302
      Width outside tires 78" 78" 78" 78" 78"
      Overall height  108" 113" 120" 108" 129"
      PTO RPM 540 540 540 540 540
      Tractor power requirement HP (kW) 102 (75) 102 (75) 102 (75) 112 (82) 109 (80)
      Tire size (4x) 435/50
      R 19.5

      435/50
      R 19.5

      435/50
      R 19.5

      435/50
      R 19.5

      435/50
      R 19.5


      The following applies to both tables:
      * Width dimensions vary according to discharge unit
      Alternative height dimensions are available on request. Ask your dealer about the available options.
