Solomix 2 ZKX TMR mixer

    The new Solomix 2 ZKX is a robust TMR mixer with two vertical augers and a hydraulic discharge door on both sides. The trailed feed mixer combines a powerful construction with the best mixing quality and the lowest total cost of ownership. The feed mixer is suitable for intensive use under harsh conditions for both large and small farms. The machine is available in sizes from 860-1285 cu.ft. Click here for an overview of the unique characteristics of our feed mixers or read more about the importance of the correct loading order for well-mixed rations

    product attributes

    Capacity 860-1285 cu.ft.
    Discharge type Side discharge doors
    Model Trailed
    Strawblower No

      Explanation of abbreviations

      • VL = Front discharge
      • H = High discharge unit
      • L = Low discharge unit
      • B = Synthetic conveyor belt
      • K = Conveyor chain
      • C = Curved conveyor chain
      • ZK = Side discharge doors
      • X = Heavy Duty

      Share

      Photos

      Video

      Standard features

      • Unique two auger drive system with two Heavy Duty planetary drives
      • Dual Flow: improved shape of the mixing tub and offset inserts
      • Two Long Life Twin Stream augers (7/8" flighting / 1" wings) for quick mixing and superior discharge
      • Reversible and adjustable drawbar with cat. III hitch ring (2400L) and hand jack
      • Adjustable low drawbar with cat. III ring (2800) and hand jack
      • 1000 RPM wide angle constant velocity PTO shaft with shearbolt (standard 1 3/4", 20 splines)
      • Two manual operated restrictor blades (reversible)
      • Single axle with two dual wheels
      • 1000 RPM reduction gearbox with cooling system
      • Hydraulic brake system
      • Two large discharge doors with rounded edges for even and rapid discharge
      • Manual adjustable discharge chute
      • Flexible and spacious side door covers on both sides
      • Right, left or dual discharge
      • To be connected directly to tractor hydraulics
      • Wear ring
      • Trioform auger knives short
      • New platform with stairs and windows
      • New in height adjustable arm for the weighing indicator

      Technical specifications

      Solomix 2 ZKX  2400L 2800 2400L ZKX-T 2800 ZKX-T  3200 ZKX-T 3600 ZKX-T*
      Capacity cu.ft. 860 1000 860 1000 1150 1285
      Overall length  304" 307" 304" 307" 324" 326"
      Width outside tires  91" 94" 86" 85" 86" 91"
      Overall height  119" 132" 120" 135" 135" 141"
      PTO RPM 1000 1000 1000 1000 1000 1000
      Tractor power requirement HP (kW) 120 (88) 130 (95) 120 (88) 130 (95) 150 (110) 177(130)
      Tire size  275/70
      R 22.5
      (4 x)
      315/80
      R 22.5
      (4 x)
      435/50
      R 19.5
      (4 x)
      385/65
      R 22.5
      (4 x)
      385/65
      R 22.5
      (4 x)
      275/70
      R 22.5
      (8 x)

      * Model 3600 ZKX-T is not available in all countries, please ask your dealer.
      Alternative height dimensions are available on request. Ask your dealer about the available options.
